VIPER Remote Control Systems
Data Outputs
Each output relay provides an isolated switch. Connections are Common (COM), Normally Open (NO) and
Normally Closed (NC).
Relay Connections when
Transmitter NOT Operating
Relay Connections when
Transmitter OPERATING
Installation
Below is a simple example showing one possible way to wire a relay in order to give switched power
to an external load:
When the relay is energised the ‘COM’ connects to ’NO’ and power is applied to the Load.
R F Solutions Ltd.,
Unit 21, Cliffe Industrial Estate,
Lewes, E. Sussex. BN8 6JL. England.
Email : sales@rfsolutions.co.uk
Tel: +44 (0)1273 898 000
http://www.rfsolutions.co.uk
Fax: +44 (0)1273 480 661
DS VIPER-4
?2009 REG No 277 4001, Lewes, England. Page 3
